Product description
10.1 inch LVDS interface, TFT, full viewing Angle, resolution of 1200*1920 LCD TFT display, for industrial control industry and related industries, can be visible under the sun.
Product parameter details
| Model | HG101WU067 | Application industry | Industrial control equipment |
| Size | 10.1-inch | Arrangement | 1920*1200 |
| Display size | 216.58mm*135.6mm | External dimensions | 228.5mm*149.3mm*4.58mm |
| Viewing Angle | ALL | Luminance | 1000cd/m2(customizable) |
| Contrast ratio | 900 | NTSC | 72% |
| Signal types | LVDS,45PIN |
| Temperature | Operating temperature in: -20℃ ~70℃, storage temperature: -30℃ ~80℃ |
| Remark | 1. High resolution, ultra-thin, highlighting products. 2. It can be visible under the sun. |
Product description
HG101WU067 is a projection row color active matrix LCD display
A TFT LCD panel, driver IC, FPC, backlight composition
It is 1200*1920 resolution, high resolution, display effect is full view LCD TFT display
45PIN LVDS-8 channel interface, can work at -20℃~70℃,
This product is widely used in industrial control, medical, handheld, security, vehicle, instruments and other related products
All products can be made with or without touch and industrial drive boards, whatever configuration you choose,
Can be customized according to your requirements (can be customized backlight, FPC, touch screen, industrial drive board)
Comply with RoHS and CE certification standards
If you cannot find a suitable one, please contact us for a recommendation.
Packing and transportation
Packing details:
1. All products are packed in the correct way to ensure safety.
2. For small size products, we use pallets = cartons.
3. For larger sizes, we use knife card + foam + carton.
4. We can also design the packaging according to customer's requirement.
transport
1. By express (3-7 working days), suitable for emergency time and small amount.
2. Sea transportation (15-30 days), suitable for routine mass production.
3. Air freight (4-5 days), from airport to airport.
Product Tags:
|
|
IPS High Resolution 1200x1920 10.1 inch TFT LCD Display LVDS Interface Images
|
